Rubber Roller Balance Machine

Feature:

1. Fast running speed

2. High reliability & precision

3. Stable performance

  Contact Now
Product Details

Product Description:

Mainly used for balance verification of large and medium-sized motor rotors, blowers, pump impellers, dryers, rollers and other rotating workpieces.

The machine adopts ring belt drive or gear box universal joint transmission, and frequency conversion motor drive to ensure the balanced quality and precision of the workpiece.

The machine has the characteristics of wide speed range, large driving power and high working efficiency.

Model Number

PHQ-3000H

PHW-3000H

2460-10000H

Transmission

Belt Drive

Universal Joint

Universal Joint

Workpiece weight range (kg)

3000

3000

10000

Workpiece Max. Outer Diameter (mm)

Ø2100

Ø2100

Ø2400

Distance between two supports (mm)

160-3780

Minimum 60

Min. 320

Support shaft diameter range (mm)

Standard Ø25 ~ 180

Standard Ø25 ~ 240

Ø60~400

The maximum diameter of the belt drive (mm)

Ø900

N/A

N/A

Rotational speed when the diameter of the workpiece transmission is 100mm (r / min)

921, 1329 + stepless speed regulation

N/A

N/A

The maximum distance from the end of the universal joint to the center of the right support (mm)

N/A

3900

6000

Spindle speed (r/min)

N/A

133,225,396.634,970 + stepless speed regulation

Stepless speed regulation

Motor Power (KW)

7.5 (AC frequency conversion)

7.5 (AC frequency conversion)

22(AC frequency conversion)

Universal coupling torque (N·m)

N/A

700

2250

Lathe length (mm)

4000

5000

7500

Minimum reachable residual imbalance / per side (e mar)

≤0.5g·mm/kg

≤1gmm / kg

≤0.5g·mm/kg

Color

Customized

Customized

Customized

Condition

New

New

New

Application:

It is widely used in the balance correction of various kinds of large and medium-sized motor rotors, impellers, crankshafts, rollers and shafts.

Services:

1. Installation service.

2. Maintenance service.

3. Technical support online service provided.

4. Technical files service provided.

5. On-site training service provided.

6. Spare parts replacement and repair service provided.


Packaging & Shipping

Packing details:

1. Outside package: Standard export wooden cases

2. Inner package: Stretch film


Shipping detail:

Within 2-4 weeks
